Key features
- GI50/125 or GI62.5/125 fibers
- Broad wavelength range
- Wavelength insensitive
- Stable coupling ratio
- Low insertion loss
- Low cost
- Custom configurations available
CP-A
Port configuration
1×2
Coupling ratio
50/50; other coupling ratios from 10/90 to 50/50
Fiber lengths on each port
1 m
Fiber type
GI 50/125 μm or GI 62.5/125 μm
Directivity
> 30 dB; guaranted by design
Uniformity
< 1,0 dB
Insertion loss*
< 4 dB; measured in a 50/50 configuration
Operating wavelength range
532 -1625 nm; depending on fiber type
Operating temperature range
-20°C to +70°C
Storage temperature range
-40°C to +85°C
