Key features
- from 100 μm to 1000 μm fiber core diameters
- broad wavelength range
- wavelength insensitive
- stable coupling ratio
- high reliability
- low insertion loss
- custom configurations available
CP-LC
Port configuration
1×2
Coupling ratio
50/50; other coupling ratios from 10/90 to 50/50
Fiber lengths on each port
1 m
Fiber type
MM SI 100 to 1000 μm core
Directivity
> 30 dB guaranted by design; higher directivity upon request
Uniformity
< 1 dB
Insertion loss
< 4 dB; measured in a 50/50 configuration
Operating wavelength range
532-1625 nm; depending on fiber type
Operating temperature range
-20°C to +70°C
Storage temperature range
-40°C to +85°C
