• RETA

    Port configuration
    1x2
    Coupling ratio
    50/50
    Fiber type
    GI 50/125μm
    Directivity
    > 55dB
    Uniformity
    1,0dB
    Insertion loss*
    < 4,0dB
    Handling power
    2W@980nm
    Operating wavelength range
    400 -1625nm
    Operating temperature range
    -20°C to +70°C
    Storage temperature range
    -40°C to +85°C

  • RETA-M16

    Port configuration
    1x2
    Coupling ratio
    50/50
    Fiber type
    GI 50/125μm
    Directivity
    > 55dB
    Uniformity
    1,0dB
    Insertion loss*
    < 4,0dB
    Handling power
    2W@980nm
    Operating wavelength range
    400 -1625nm
    Operating temperature range
    -20°C to +70°C
    Storage temperature range
    -40°C to +85°C

  • RETA-M30

    Port configuration
    1x2
    Coupling ratio
    50/50
    Fiber type
    GI 50/125μm
    Directivity
    > 55dB
    Uniformity
    1,0dB
    Insertion loss*
    < 4,0dB
    Handling power
    2W@980nm
    Operating wavelength range
    400 -1625nm
    Operating temperature range
    -20°C to +70°C
    Storage temperature range
    -40°C to +85°C
